SOLARAXY Solar Wall Lamp

SOTTLOT SOLARAXY AWM-01 solar wall light with Tracker technology (360° solar tracking), 300 lm / 3000K, Bluetooth Mesh networking, and professional outdoor durability IP66 / IK10 / C4H.

Rated rain-day backup > 10 days with default lighting mode 100% for 5h + 20% until dawn.

Key benefits

* 360° Solar Tracking (Tracker): real-time calculation to maximize solar energy capture; charging efficiency claimed up to +30% vs similar products.
* Dark Sky design: reduces light pollution while maintaining a decorative lighting effect.
* Outdoor durability: IP66 / IK10 / C4H.
* Networking: Bluetooth Mesh.
* Battery level indicator: Green ≥70% / Orange 30–70% / Red <30%.

Specifications

* Model: AWM-01
* Type: solar wall light
* Product dimensions: 214.8 × 285.3 × 338.2 mm
* Luminous flux: 300 lm
* CCT: 3000K
* LEDs: Osram 3030 / 20 pcs
* Solar panel: 4.3V / 2.8W
* Li-ion battery: 5Ah × 2 / 3.7V / 37Wh
* Rainy-day backup: > 10 days
* Default lighting mode: 100% for 5h + 20% until dawn
* Lighting area: 9 m
* Technologies: ALS 2.5 / TCS 3.0
* Charging / discharging temperature: 0~45°C / -20~60°C
* Network: Bluetooth Mesh
* Protection / impact rating: IP66 / IK10 / C4H
* Button control: ON/OFF (long press 1.5s); Reset (long press 6s)

In the box

* Bracket: 1 pc
* Instructions: 1 pc
* Screws: 1 set

Logistics (Packaging)

*Weights are “for reference only.”

Inner box (1 pc / 1 box)

* 330 × 235 × 435 mm
* N/W: 2.36 kg
* G/W: 3.17 kg

Master carton (4 boxes / CTN)

* 675 × 485 × 440 mm
* N/W: 9.50 kg
* G/W: 14.30 kg
* 1 layer = 4 boxes
